Diamond® 400 Diamond 400
As its name implies, the Diamond 400 Series has a tough, durable coating. Also featuring excellent abrasion resistance, the Diamond Series is the perfect webbing for driving harnesses and adjustable straps. See the various colors and profiles available for this coated webbing product.
Width and Profile Options
* Break strength value is per inch of width. Example 2’’ (50.8mm) is 2000lbs (907.1847kg) or 3/4’’ (19.05mm) is 750lbs (340.194kg). ASTM D6775-02
** All Hole Pull Strength values are based on a 1’’ wide specimen. ASTM D4831
| Profile | Thickness | Break Strength * |
Hole Pull Strength ** |
Available Widths |
|---|---|---|---|---|
B05 Ultra Thin |
.030" - .040", .76mm - 1.02mm | 400lbs (181.437kg) | 40lbs (18.144kg) |
3/8" (9.52 mm)
1/2" (12.70 mm)
5/8" (15.87 mm)
3/4" (19.05 mm)
1" (25.40 mm)
1 1/2" (38.10 mm)
2" (50.80 mm)
|
B05 Super Flex |
.055" - .065", 1.40mm - 1.65mm | 400lbs (181.437kg) | 40lbs (18.144kg) |
3/8" (9.52 mm)
1/2" (12.70 mm)
5/8" (15.87 mm)
3/4" (19.05 mm)
1" (25.40 mm)
1 1/2" (38.10 mm)
2" (50.80 mm)
|
B07 Ultra Thin |
.030" - .040", .76mm - 1.02mm | 600lbs (272.155kd) | 100lbs (45.359kg) |
3/8" (9.52 mm)
1/2" (12.70 mm)
5/8" (15.87 mm)
3/4" (19.05 mm)
1" (25.40 mm)
1 1/2" (38.10 mm)
2" (50.80 mm)
3" (76.20 mm)
|
B07 Super Flex |
.055" - .065", 1.40mm - 1.65mm | 600lbs (272.155kd) | 100lbs (45.359kg) |
3/8" (9.52 mm)
1/2" (12.70 mm)
5/8" (15.87 mm)
3/4" (19.05 mm)
1" (25.40 mm)
1 1/2" (38.10 mm)
2" (50.80 mm)
4" (101.60 mm)
|
B10 Super Flex |
.055" - .065", 1.40mm - 1.65mm | 1000lbs (453.592kg) | 200lbs (90.719kg) |
3/8" (9.52 mm)
1/2" (12.70 mm)
9/16" (14.28 mm)
5/8" (15.87 mm)
3/4" (19.05 mm)
7/8" (22.22 mm)
1" (25.40 mm)
1 1/8" (28.57 mm)
1 1/4" (31.75 mm)
1 1/2" (38.10 mm)
2" (50.80 mm)
2 1/2" (63.50 mm)
3" (76.20 mm)
4" (101.60 mm)
|
B10 High Flex |
.075" - .085", 1.91mm - 2.16mm | 1000lbs (453.592kg) | 200lbs (90.719kg) |
3/8" (9.52 mm)
1/2" (12.70 mm)
9/16" (14.28 mm)
5/8" (15.87 mm)
3/4" (19.05 mm)
7/8" (22.22 mm)
1" (25.40 mm)
1 1/8" (28.57 mm)
1 1/4" (31.75 mm)
1 1/2" (38.10 mm)
2" (50.80 mm)
2 1/2" (63.50 mm)
3" (76.20 mm)
4" (101.60 mm)
|
B10 Standard |
.095" - .105", 2.41mm - 2.67mm | 1000lbs (453.592kg) | 200lbs (90.719kg) |
3/8" (9.52 mm)
1/2" (12.70 mm)
9/16" (14.28 mm)
5/8" (15.87 mm)
3/4" (19.05 mm)
7/8" (22.22 mm)
1" (25.40 mm)
1 1/8" (28.57 mm)
1 1/4" (31.75 mm)
1 1/2" (38.10 mm)
2" (50.80 mm)
2 1/2" (63.50 mm)
3" (76.20 mm)
4" (101.60 mm)
|
B10 Grooved |
.095" - .105", 2.41mm - 2.67mm | 1000lbs (453.592kg) | 200lbs (90.719kg) |
3/8" (9.52 mm)
1/2" (12.70 mm)
9/16" (14.28 mm)
5/8" (15.87 mm)
3/4" (19.05 mm)
7/8" (22.22 mm)
1" (25.40 mm)
1 1/8" (28.57 mm)
1 1/4" (31.75 mm)
1 1/2" (38.10 mm)
2" (50.80 mm)
2 1/2" (63.50 mm)
3" (76.20 mm)
4" (101.60 mm)
|
B10 Beaded |
.150" - .170", 3.81mm - 4.32mm | 1000lbs (453.592kg) | 200lbs (90.719kg) |
3/8" (9.52 mm)
1/2" (12.70 mm)
9/16" (14.28 mm)
5/8" (15.87 mm)
3/4" (19.05 mm)
7/8" (22.22 mm)
1" (25.40 mm)
1 1/8" (28.57 mm)
1 1/4" (31.75 mm)
1 1/2" (38.10 mm)
2" (50.80 mm)
2 1/2" (63.50 mm)
3" (76.20 mm)
4" (101.60 mm)
|
B10 Ex Thick Grooved |
.125" - .135", 3.17mm - 3.43mm | 1000lbs (453.592kg) | 200lbs (90.719kg) |
3/8" (9.52 mm)
1/2" (12.70 mm)
9/16" (14.28 mm)
5/8" (15.87 mm)
3/4" (19.05 mm)
7/8" (22.22 mm)
1" (25.40 mm)
1 1/8" (28.57 mm)
1 1/4" (31.75 mm)
1 1/2" (38.10 mm)
2" (50.80 mm)
2 1/2" (63.50 mm)
3" (76.20 mm)
4" (101.60 mm)
|
B10 Super Heavy Grooved |
.140" - .160", 3.56mm - 4.06mm | 1000lbs (453.592kg) | 200lbs (90.719kg) |
3/8" (9.52 mm)
1/2" (12.70 mm)
9/16" (14.28 mm)
5/8" (15.87 mm)
3/4" (19.05 mm)
7/8" (22.22 mm)
1" (25.40 mm)
1 1/8" (28.57 mm)
1 1/4" (31.75 mm)
1 1/2" (38.10 mm)
2" (50.80 mm)
2 1/2" (63.50 mm)
3" (76.20 mm)
4" (101.60 mm)
|
B30 Super Heavy |
.130" - .160", 3.30mm - 4.06mm | 3000lbs (1360.777kg) | 700lbs (317.515kg) |
3/4" (19.05 mm)
1" (25.40 mm)
1 1/4" (31.75 mm)
2" (50.80 mm)
|
B30 Super Heavy Grooved |
.140" - .160", 3.56mm - 4.06mm | 3000lbs (1360.777kg) | 700lbs (317.515kg) |
3/4" (19.05 mm)
1" (25.40 mm)
1 1/4" (31.75 mm)
1 1/2" (38.10 mm)
2" (50.80 mm)
|
B30 Super Thick Grooved |
.175" - .195", 4.45mm - 4.95mm | 3000lbs (1360.777kg) | 700lbs (317.515kg) |
3/4" (19.05 mm)
1" (25.40 mm)
1 1/4" (31.75 mm)
1 1/2" (38.10 mm)
2" (50.80 mm)
|
Buy a Sample
Thickness: 0.035'' (0.88 mm) - Ultra Thin (UT)
Break Strength: 1,000lbf (453kgf)
Hole Pull: 100lbf (45kgf)
Width: 2" (50.80 mm)
Gloss: High Gloss
Base Price: $69.25 / 50' Roll
Thickness: 0.035'' (0.88 mm) - Ultra Thin (UT)
Break Strength: 1,700lbf (771kgf)
Hole Pull: 100lbf (45kgf)
Width: 2" (50.80 mm)
Gloss: High Gloss
Base Price: $69.25 / 50' Roll
Thickness: 0.035'' (0.88 mm) - Ultra Thin (UT)
Break Strength: 3,500lbf (1587kgf)
Hole Pull: 200lbf (90kgf)
Width: 2" (50.80 mm)
Gloss: High Gloss
Base Price: $108.30 / 50' Roll
Thickness: 0.050" (1.27 mm) - Thin Flex (TF)
Break Strength: 2,500lbf (1133kgf)
Hole Pull: 200lbf (90kgf)
Width: 2" (50.80 mm)
Gloss: High Gloss
Base Price: $82.45 / 50' Roll
Thickness: 0.060" (1.52 mm) - Super Flex (SF)
Break Strength: 3,500lbf (1587kgf)
Hole Pull: 200lbf (90kgf)
Width: 2" (50.80 mm)
Gloss: High Gloss
Base Price: $86.80 / 50' Roll
Thickness: 0.050" (1.27 mm) - Thin Flex (TF)
Break Strength: 4,200lbf (1905kgf)
Hole Pull: 200lbf (90kgf)
Width: 2" (50.80 mm)
Gloss: High Gloss
Base Price: $60.15 / 50' Roll
Thickness: 0.060" (1.52 mm) - Super Flex (SF)
Break Strength: 5,500lbf (2494kgf)
Hole Pull: 200lbf (90kgf)
Width: 2" (50.80 mm)
Gloss: High Gloss
Base Price: $94.50 / 50' Roll
Thickness: 0.060" (1.52 mm) - Super Flex (SF)
Break Strength: 7,800lbf (3538kgf)
Hole Pull: 200lbf (90kgf)
Width: 2" (50.80 mm)
Gloss: High Gloss
Base Price: $82.20 / 50' Roll
Thickness: 0.035'' (0.88 mm) - Ultra Thin (UT)
Break Strength: 500lbf (226kgf)
Hole Pull: 60lbf (27kgf)
Width: 1" (25.40 mm)
Gloss: High Gloss
Base Price: $43.15 / 50' Roll
Thickness: 0.035'' (0.88 mm) - Ultra Thin (UT)
Break Strength: 625lbf (283kgf)
Hole Pull: 100lbf (45kgf)
Width: 1" (25.40 mm)
Gloss: High Gloss
Base Price: $43.15 / 50' Roll
Thickness: 0.050" (1.27 mm) - Thin Flex (TF)
Break Strength: 1,250lbf (566kgf)
Hole Pull: 250lbf (113kgf)
Width: 1" (25.40 mm)
Gloss: High Gloss
Base Price: $46.30 / 50' Roll
Thickness: 0.035'' (0.88 mm) - Ultra Thin (UT)
Break Strength: 800lbf (362kgf)
Hole Pull: 100lbf (45kgf)
Width: 1 1/2" (38.10 mm)
Gloss: High Gloss
Base Price: $60.30 / 50' Roll
Thickness: 0.035'' (0.88 mm) - Ultra Thin (UT)
Break Strength: 1,100lbf (498kgf)
Hole Pull: 100lbf (45kgf)
Width: 1 1/2" (38.10 mm)
Gloss: High Gloss
Base Price: $60.30 / 50' Roll
Thickness: 0.060" (1.52 mm) - Super Flex (SF)
Break Strength: 2,800lbf (1270kgf)
Hole Pull: 250lbf (113kgf)
Width: 1 1/2" (38.10 mm)
Gloss: High Gloss
Base Price: $63.45 / 50' Roll
Thickness: 0.035'' (0.88 mm) - Ultra Thin (UT)
Break Strength: 450lbf (204kgf)
Hole Pull: 90lbf (40kbf)
Width: 3/4" (19.05 mm)
Gloss: High Gloss
Base Price: $36.70 / 50' Roll
Thickness: 0.050" (1.27 mm) - Thin Flex (TF)
Break Strength: 825lbf (374kgf)
Hole Pull: 130lbf (58kgf)
Width: 3/4" (19.05 mm)
Gloss: High Gloss
Base Price: $39.10 / 50' Roll
Thickness: 0.035'' (0.88 mm) - Ultra Thin (UT)
Break Strength: 300lbf (136kgf)
Hole Pull: 50lbf (22kgf)
Width: 1/2" (12.70 mm)
Gloss: High Gloss
Base Price: $33.68 / 50' Roll
Thickness: 0.050" (1.27 mm) - Thin Flex (TF)
Break Strength: 550lbf (249kgf)
Hole Pull: 120lbf (54kbf)
Width: 1/2" (12.70 mm)
Gloss: High Gloss
Base Price: $36.10 / 50' Roll
Thickness: 0.035'' (0.88 mm) - Ultra Thin (UT)
Break Strength: 1,750lbf (793kgf)
Hole Pull: 100lbf (45kgf)
Width: 3" (76.20 mm)
Gloss: High Gloss
Base Price: $109.15 / 50' Roll
Thickness: 0.055" (1.39 mm) - Ultra Flex (UF)
Break Strength: 4,800lbf (2177kgf)
Hole Pull: 290lbf (131kgf)
Width: 3" (76.20 mm)
Gloss: High Gloss
Base Price: $135.50 / 50' Roll
Thickness: 0.035'' (0.88 mm) - Ultra Thin (UT)
Break Strength: 2,400lbf (1088kgf)
Hole Pull: 100lbf (45kgf)
Width: 4" (101.60 mm)
Gloss: High Gloss
Base Price: $148.45 / 50' Roll
Thickness: 0.055" (1.39 mm) - Ultra Flex (UF)
Break Strength: 6,200lbf (2812kgf)
Hole Pull: 290lbf (131kgf)
Width: 4" (101.60 mm)
Gloss: High Gloss
Base Price: $174.25 / 50' Roll
Thickness: 0.035'' (0.88 mm) - Ultra Thin (UT)
Break Strength: 200lbf (90kgf)
Hole Pull: 40lbf (18kgf)
Width: 3/8" (9.52 mm)
Gloss: High Gloss
Base Price: $32.25 / 50' Roll
Thickness: 0.050" (1.27 mm) - Thin Flex (TF)
Break Strength: 400lbf (181kgf)
Hole Pull: 100lbf (45kgf)
Width: 3/8" (9.52 mm)
Gloss: High Gloss
Base Price: $34.50 / 50' Roll
Thickness: 0.035'' (0.88 mm) - Ultra Thin (UT)
Break Strength: 350lbf (158kgf)
Hole Pull: 50lbf (22kgf)
Width: 5/8" (15.87 mm)
Gloss: High Gloss
Base Price: $35.05 / 50' Roll
Thickness: 0.050" (1.27 mm) - Thin Flex (TF)
Break Strength: 650lbf (294kgf)
Hole Pull: 130lbf (58kgf)
Width: 5/8" (15.87 mm)
Gloss: High Gloss
Base Price: $37.45 / 50' Roll
Thickness: 0.235" (5.97 mm) - Coated Rope (CR)
Break Strength: 400lbf (181kgf)
Hole Pull: N/A
Width: 1/4" (6.35 mm) Rope
Gloss: High Gloss
Base Price: $30.00 / 15' Roll
